Flocked Pile Polishing Film for Roller Finishing and LCD Wiping

Flocked Polishing Film

Top Layer: High-density electrostatic flocking for maximum cushioning and particle absorption.

Base Film: High-tensile PET film for stable tension control in LCD wiping tape rolls.

Everaging its exceptional cushioning properties and effective cleaning capabilities, flocked pile polishing film roll widely utilized in the final stage of polishing processes for rollers and LCD panels—particularly for ITO-patterned panels.

Extraordinary Anti-scratch Effect：The flocked substrate is soft and possesses excellent cushioning properties and debris-retention capabilities, effectively preventing scratches.

Excellent Grinding Consistency： Produces a uniform grinding effect, with stable grinding and cleaning efficiency. Effectively prevents surface scratching.

Application: Industrial Roller, LCD panel

material

Diameter [mm]

15mm*0.838m

55mm*74mm

101.6mm*23m

135mm*20m

160mm*15m

190mm*20m

200mm*10m

abrasive

Aluminium oxide

Aluminium hydroxide

CaCO₃

Send Email

Chat Now

Share With:

1

The flocked pile polishing film roll is composed of a composite of micron- or sub-micron-scale abrasives and novel polymer particles, surface coated by a layer of these materials.

2

Unique construction makes it the ultimate cleanroom flocked abrasive film, ensuring your yield rate stays high by eliminating the primary cause of surface contamination.

3

Anti-Scratch Technology: Soft pile structure prevents secondary scratches on delicate optical films.

4

100% Lint-Free: Engineered for Cleanroom environments, exceeding standard LCD wiping requirements.

5

Superior Particle Trap: The 3D flocking design lifts and locks dust away from the work surface.

6

Customizable: Available in various grit sizes and roll widths (LCD wiping tape roll compatible).

Versatile Applications Across High-Precision Industries

Flocked cleaning film is not just a consumable; it’s a yield-improvement tool used in:

Flocked Pile Tape is specifically optimized for high-value rollers where surface integrity is non-negotiable:

Mirror Roller Polishing: Achieve ultra-low Ra values on chrome-plated, ceramic, and stainless steel rollers without the risk of “hot spots” or scratching.
Gravure & Flexo Rollers: Safely clean and polish cell structures without damaging the delicate engraving.
LCD & Film Stretching Rollers: The preferred LCD wiping tape roll for cleaning high-speed rollers in optical film production lines, ensuring zero lint and zero defects.
Semiconductor Wafer Chucks: Precision cleaning using our cleanroom flocked abrasive film to maintain extreme flatness and cleanliness.
Precision Optics: Soft-touch polishing for high-end lenses and prisms where traditional abrasives are too aggressive.

Learn More

Model Overview

Abrasive grit/Abrasive	Aluminium oxide	Aluminium hydroxide	CaCO₃
20µm #800	-	√	√	Get a quote
1µm #8000	√	-	-	Get a quote
0.5µm #10000	√	-	-	Get a quote
